Screw Conveyor Flow Rate Calculator

To determine the flow rate of a screw conveyor, multiply the cross-sectional area of the material being conveyed by the screw’s rotational speed, the pitch, and additional efficiency and material parameters.

Screw Conveyor Flow Rate Calculator

Enter all values to calculate the flow rate

The Screw Conveyor Flow Rate Calculator is a practical tool for engineers, plant operators, and designers working with bulk material handling. This calculator provides an easy way to estimate the flow rate of materials being transported by a screw conveyor, ensuring optimal operation and efficiency.

Whether designing new equipment or optimizing an existing setup, this tool assists in achieving precise and effective material flow. Accurate calculations not only reduce material wastage but also enhance process efficiency.

Formula

Q = 60 ∗ π/4 ∗ D² ∗ S ∗ N ∗ a ∗ d ∗ C

Variable Description Unit
Q Flow Rate Cubic meters/hour
D Screw Diameter Meters
S Screw Pitch Meters
N Rotational Speed RPM
a Load Efficiency Factor Dimensionless
d Material Density Kilograms/m³
C Conveyor Capacity Correction Factor Dimensionless
READ ALSO:  Wheel Horsepower Calculator

Solved Calculations

Example 1: Calculate the flow rate for a screw conveyor with the following specifications:

  • Screw diameter: 0.5 m
  • Screw pitch: 0.2 m
  • Rotational speed: 50 RPM
  • Load efficiency: 0.9
  • Material density: 800 kg/m³
  • Conveyor capacity correction factor: 0.85
Step Calculation Result
Cross-sectional area π/4D2=π/4(0.5)2π/4 ∗ D² = π/4 ∗ (0.5)²
0.196 m²
Flow rate calculation Q=600.1960.2500.98000.85Q = 60 ∗ 0.196 ∗ 0.2 ∗ 50 ∗ 0.9 ∗ 800 ∗ 0.85
44.92 m³/h



Example 2: Calculate the flow rate for a screw conveyor where:

  • Screw diameter: 0.4 m
  • Screw pitch: 0.15 m
  • Rotational speed: 40 RPM
  • Load efficiency: 0.8
  • Material density: 600 kg/m³
  • Conveyor capacity correction factor: 0.9
Step Calculation Result
Cross-sectional area π/4D2=π/4(0.4)2π/4 ∗ D² = π/4 ∗ (0.4)²
0.126 m²
Flow rate calculation Q=600.1260.15400.86000.9Q = 60 ∗ 0.126 ∗ 0.15 ∗ 40 ∗ 0.8 ∗ 600 ∗ 0.9
15.45 m³/h

What is Screw Conveyor Flow Rate Calculator?

The Screw Conveyor Flow Rate Calculator is a practical tool designed to estimate the flow rate or capacity of screw conveyors.

It helps engineers, manufacturers, and plant operators determine the optimal specifications for material transportation in industries like agriculture, construction, and manufacturing.

By leveraging variables such as screw diameter, pitch, speed, and fill rate, this calculator simplifies the otherwise complex process of conveyor design.

For example, users can input the screw diameter, rotation speed (RPM), and material density to compute flow rate in tons per hour or cubic meters per minute.

READ ALSO:  Blood Pressure Index Calculator

It also considers parameters like conveyor incline and material type for accurate results. Supporting formats like PDF, Excel, and metric units, this calculator is versatile for various applications.

Final Words:

In conclusion, the Screw Conveyor Flow Rate Calculator is an indispensable tool for streamlining material handling processes. With its ability to ensure precision and efficiency, it caters to professionals seeking optimized screw conveyor designs for maximum productivity.
